HR1500H - Tuff Tarper, Alum Fr

Product Description

System Overview:

The HR1500E Tuff-Tarper with Aluminum Frame is part of the Tuff-Tarper Series, engineered for single-axle cable hoist and hooklift trucks. These systems are designed to cover open-top, fixed-height containers ranging from 8 feet to 16 feet in length.

Tuff-Tarper systems are available in semi-automatic, automatic, and hydraulic models, providing flexibility and reliability for daily operations.

HR1500HAL Tuff-Tarper with Hydraulic Gantry

The HR1500HAL is a hydraulic tarp system built for single-axle hooklift trucks. It is designed for durability, safety, and long-term tarp protection.

Key Features:

• Direct Drive Hydraulic Motor: Quiet, smooth, and steady operation

• Adjustable Roller Assembly: Mounted on a hydraulic gantry with vertical range of 60 inches to 96 inches (5.0 feet to 8.0 feet)

• Truck Integration: Uses existing truck hydraulic system

• Side-Mounted Aluminum Pivot Arms: Reduced weight and durable

• Heavy-Duty Reverse-Wound Torsion Springs: Assist pivot arm deployment

• Flow Diverter and Cover Control Valve: Safe, low-pressure roller operation

• Heavy-Duty Mesh Tarp Included: 9 feet wide, expandable

• Easy Installation and Low Maintenance Design

Tuff-Tarper Advantages:

• Adjustable Gantry: Extends tarp life by gently lowering over the load instead of dragging

• Telescopic or Fixed Gantries: Require 10 inches of clearance for roller rest; fixed gantry may be modified for limited clearance applications

• Standard Tarp: 9 feet wide expandable heavy-duty mesh

Parts Included:

Arms & Structural Components:

• Arm Mounting Bracket

• Retaining Ring (Side Mount)

• Left and Right Side Base Arm (Side Mount)

• Upper Arm — 9-1/2 feet Aluminum

• 2 Straight Bow Corners

• Rear Section — 9 feet Aluminum

Roller & Gantry Components:

• Roller Assembly

• Gantry Assembly

• Gantry Cylinder — 36-Inch Lift

• Cover Spring

Hydraulic Components & Fittings:

• Flow Diverter — 5 Gallons Per Minute

• Cover Control Valve — 2-Spool

• Hydraulic Hose — 6 Inch x 9 Feet

• Hydraulic Hose — 6 Inch x 6 Feet

• 90-Degree Elbow

• -8 SAE Male x -8 JIC Female 90-Degree Elbow

• -6 SAE Male x -6 JIC Female 90-Degree Elbow

• -6 SAE Male x -8 JIC Male Straight Adapter

• SAE Male Plug

• Adapter

Hardware & Miscellaneous:

• Roll Pin — 5/16" x 1-1/2"

• Clevis Pin with Cotter

• Chassis Mounting Angle

Replacement Covers Available:

• 9 feet x 19 feet Heavy-Duty Mesh Tarp

• 9 feet x 19 feet Deluxe Asphalt Tarp
