Product Description
The Standard for Heavy-Duty Heat Treatment & Thermal Insulation
When high-temperature thermal insulation and heat treatment operations demand uncompromising performance, the 24 oz. Insul-Shield Fiberglass Welding Blanket delivers. Designed specifically for stress relieving, annealing, and heavy-duty thermal protection, this premium blanket provides an exceptional continuous temperature rating of 1000°F. Unlike standard welding blankets designed primarily for spark protection, the Insul-Shield series is engineered for sustained thermal insulation. The dense 24 oz. fiberglass construction traps heat effectively, making it the preferred choice for controlled cooling of metal components, protecting sensitive machinery from radiant heat, and establishing safe perimeters around high-temperature operations.
For over 75 years, DeBrovys has been the trusted partner for industrial thermal protection solutions. Every 24 oz. Insul-Shield fiberglass welding blanket is manufactured to exacting specifications, ensuring consistent performance and durability across the most demanding industrial environments. Whether you are operating in a heat-treating facility, a power generation plant, a shipyard, or an aerospace manufacturing center, the 24 oz. Insul-Shield fiberglass welding blanket provides the reliable thermal protection required to maintain safety and operational continuity.
Why Choose 24 oz. Insul-Shield Fiberglass?
The core advantage of the 24 oz. Insul-Shield blanket lies in its un-coated, heat-treated fiberglass construction. While coated blankets (like silicone, neoprene, or acrylic) are excellent for shedding sparks and fluids, they often sacrifice pure thermal insulation capacity. The Insul-Shield's woven fiberglass structure is specifically designed to maximize thermal resistance and minimize heat transfer, making it superior for applications requiring sustained heat retention and controlled cooling.
The heat-treating process applied to this fabric burns off sizing and organic binders, resulting in a cleaner, more stable material that won't smoke or outgas significantly when exposed to high temperatures. This proprietary heat treatment distinguishes the Insul-Shield from standard fiberglass products, providing superior performance in stress-relieving and annealing operations where thermal stability is critical.
The 24 oz. weight strikes the perfect balance between heavy-duty insulation and practical flexibility, allowing it to be wrapped around pipes, draped over castings, or hung as a thermal barrier. This versatility, combined with the un-coated fiberglass's superior insulating properties, makes the 24 oz. Insul-Shield the preferred choice for industrial thermal management applications worldwide.
Technical Specifications
Professionals who rely on the 24 oz. Insul-Shield fiberglass welding blanket demand precise technical specifications to ensure it meets their exacting requirements. DeBrovys is committed to transparency and quality, providing the following detailed specifications:
| Base Material | Heat-Treated Woven Fiberglass |
|---|---|
| Coating | Un-coated (Heat Treated) |
| Fabric Weight | 24 oz. per square yard |
| Thickness | 0.035" (approximate) |
| Continuous Temp Rating | 1000°F (537°C) |
| Intermittent Temp Rating | 1500°F (815°C) |
| Color | White / Beige |
| Hardware | Heavy-Duty Brass Grommets |
| Grommet Spacing | Every 24 inches on all four sides |
| Hem Construction | Folded and stitched with high-temp thread |
The integration of heavy-duty brass grommets spaced every 24 inches is a critical feature that enhances the utility of the 24 oz. Insul-Shield fiberglass welding blanket. These brass grommets allow for secure, rapid deployment as a hanging curtain, a suspended heat shield, or a securely tied-down protective cover. The brass construction ensures the grommets will not rust or degrade, maintaining the longevity and reliability of the 24 oz. Insul-Shield even in harsh, corrosive industrial environments.
Regulatory Compliance & Industry Standards
Key Hot Work Safety Standards Addressed
Deploying the 24 oz. Insul-Shield fiberglass welding blanket helps facilities maintain compliance with critical safety regulations:
- NFPA 51B Compliance: Meets the National Fire Protection Association's strict requirements for fire prevention during welding, cutting, and other hot work. The Insul-Shield's thermal properties support safe work zone establishment and personnel protection protocols.
- OSHA 1910.252 Alignment: Supports Occupational Safety and Health Administration mandates for protecting personnel and combustible materials from welding hazards. The blanket's 1000°F continuous rating ensures compliance with workplace thermal protection requirements.
- ANSI Z49.1 Support: Aligns with the American National Standards Institute's guidelines for safety in welding and cutting operations, including thermal insulation and heat management protocols.
- FM 4950 Approval: Meets Factory Mutual standards for industrial thermal protection equipment, ensuring the blanket performs reliably in demanding manufacturing environments.
These regulatory alignments demonstrate that the 24 oz. Insul-Shield fiberglass welding blanket is engineered not just for performance, but for compliance with the most stringent industrial safety standards.
Application Versatility: Thermal Blankets vs. Curtains
Horizontal Thermal Blankets (Draping & Wrapping)
The primary use case for the 24 oz. Insul-Shield is as a horizontal thermal blanket. Its flexible woven structure allows it to be wrapped tightly around pipes for stress relieving, draped over freshly welded castings for controlled cooling, or placed over sensitive equipment to protect against radiant heat. The un-coated fiberglass excels at trapping air and resisting thermal transfer, making it ideal for applications where heat retention is as important as heat protection.
In stress-relieving operations, the Insul-Shield blanket's thermal insulation properties ensure that metal components cool slowly and uniformly, reducing residual stress and preventing warping or cracking. This controlled cooling capability is essential for high-precision manufacturing and aerospace applications.
Vertical Thermal Curtains (Hanging)
Equipped with brass grommets every 24 inches, this blanket can also be suspended vertically to create thermal barriers. While it can serve as a welding curtain for spark protection, its true value in vertical applications is isolating heat-generating equipment (like furnaces or large welding operations) from adjacent work areas, protecting personnel from radiant heat exposure.
The vertical deployment capability makes the 24 oz. Insul-Shield ideal for creating temporary or permanent thermal zones in manufacturing facilities, protecting nearby equipment and personnel from high-temperature operations.
The DeBrovys Industrial Guarantee
For over 75 years, DeBrovys has been the trusted partner for industrial fabrics and safety equipment. Every 24 oz. Insul-Shield fiberglass welding blanket is manufactured to exact specifications, ensuring consistent thermal performance and durability. We stand behind every product with our commitment to quality and customer satisfaction.
Need a Custom Solution? If our standard sizes don't fit your specific heat-treating or insulation requirements, we offer comprehensive custom fabrication services. From specialized cut-outs and custom grommet spacing to heat-sealed panels and custom enclosures, our fabrication team can build exactly what you need. Contact us for a custom quote and let our experts help you find the perfect thermal protection solution for your operation.
Comprehensive Size Range & Pricing
Recognizing that industrial applications vary significantly in scale, DeBrovys offers the 24 oz. Insul-Shield fiberglass blanket in a comprehensive array of sizes. From localized spot protection to expansive area coverage, there is a 24 oz. Insul-Shield configured to meet your specific requirements. Each size variant features the same premium construction, heat-treated fiberglass, and brass grommets spaced every 24 inches.
| Size | Coverage Area | Price | Application Group |
|---|---|---|---|
| 3' x 3' | 9 sq. ft. | $24.95 | Small Coverage |
| 3' x 4' | 12 sq. ft. | $29.95 | Small Coverage |
| 4' x 5' | 20 sq. ft. | $49.91 | Small Coverage |
| 4' x 6' | 24 sq. ft. | $59.89 | Small Coverage |
| 5' x 5' | 25 sq. ft. | $62.39 | Medium Coverage |
| 5' x 6' | 30 sq. ft. | $74.86 | Medium Coverage |
| 6' x 6' | 36 sq. ft. | $89.84 | Medium Coverage |
| 6' x 8' | 48 sq. ft. | $119.78 | Medium Coverage |
| 6' x 9' | 54 sq. ft. | $134.76 | Medium Coverage |
| 6' x 10' | 60 sq. ft. | $149.73 | Medium Coverage |
| 8' x 8' | 64 sq. ft. | $159.71 | Medium Coverage |
| 8' x 10' | 80 sq. ft. | $199.64 | Medium Coverage |
| 9' x 12' | 108 sq. ft. | $269.51 | Large Coverage |
| 9' x 15' | 135 sq. ft. | $336.89 | Large Coverage |
| 9' x 18' | 162 sq. ft. | $404.27 | Large Coverage |
| 10' x 10' | 100 sq. ft. | $249.55 | Large Coverage |
| 10' x 12' | 120 sq. ft. | $299.46 | Large Coverage |
| 10' x 15' | 150 sq. ft. | $374.32 | Large Coverage |
| 12' x 12' | 144 sq. ft. | $449.19 | Large Coverage |
| 12' x 18' | 216 sq. ft. | $598.92 | Large Coverage |
| 12' x 20' | 240 sq. ft. | $598.92 | Large Coverage |
Primary Industries & Applications
The 24 oz. Insul-Shield fiberglass welding blanket serves a wide range of industrial sectors where thermal management and heat control are critical to operations and safety:
- Heat Treating & Stress Relieving: Essential for wrapping pipes and castings to ensure slow, controlled cooling rates. The Insul-Shield's thermal insulation properties make it the preferred choice for stress-relieving operations in manufacturing facilities.
- Power Generation & Refineries: Thermal insulation for high-temperature valves, flanges, and exhaust systems. The blanket protects personnel and adjacent equipment from intense radiant heat in power plants and refinery operations.
- Shipbuilding & Marine: Protecting bulkheads and sensitive equipment from radiant heat during heavy welding operations. The Insul-Shield's durability and thermal performance make it ideal for demanding marine environments.
- Automotive & Aerospace: Thermal barriers for engine testing, exhaust insulation, and high-temp manufacturing processes. Aerospace manufacturers rely on the Insul-Shield for precision thermal control in critical applications.
- Heavy Fabrication: Creating safe thermal zones and protecting adjacent machinery from furnace or welding heat. The blanket's versatility makes it invaluable in complex fabrication environments.
- Foundries & Metal Casting: Protecting molds and surrounding equipment from extreme temperatures during metal casting operations.
24 oz. Insul-Shield vs. Coated Welding Blankets
Understanding the differences between un-coated and coated welding blankets is essential for selecting the right thermal protection solution for your application:
Un-Coated Insul-Shield (24 oz.)
- Superior thermal insulation and heat retention
- Ideal for stress relieving and controlled cooling applications
- Minimal smoke and outgassing due to heat treatment
- Excellent for wrapping and draping applications
- Lower cost per unit
- Best for heat management rather than spark protection
Coated Welding Blankets (Silicone, Neoprene, Acrylic)
- Superior spark and spatter protection
- Better fluid resistance (oil, coolant, water)
- Easier to clean and maintain
- Better for heavy welding and cutting operations
- Higher cost
- Reduced thermal insulation capacity
The Bottom Line: If your primary need is thermal insulation and heat management, the 24 oz. Insul-Shield is the superior choice. If you need maximum spark and spatter protection with fluid resistance, a coated blanket may be more appropriate. Many facilities use both types in different areas of their operations.
Frequently Asked Questions (FAQ)
What is the difference between Insul-Shield and coated welding blankets?
Coated blankets (like silicone, neoprene, or acrylic) are designed primarily to shed sparks, slag, and fluids. The Insul-Shield is un-coated, heat-treated fiberglass designed specifically for thermal insulation and heat retention. It is better at trapping heat for stress relieving, while coated blankets are better for heavy spatter protection.
Can the 24 oz. Insul-Shield be used for stress relieving?
Yes, this is one of its primary applications. The 24 oz. weight provides excellent thermal insulation, allowing it to be wrapped around pipes or draped over welds to ensure a slow, controlled cooling process, which is critical for stress relieving and preventing residual stress in metal components.
Does this blanket produce smoke when heated?
Because the Insul-Shield fiberglass is heat-treated during manufacturing to remove sizing and organic binders, it produces significantly less smoke and outgassing compared to standard, non-treated fiberglass when exposed to high temperatures. This makes it ideal for indoor applications where air quality is a concern.
Is the 24 oz. Insul-Shield itchy to handle?
Like all un-coated fiberglass products, it can cause skin irritation. We strongly recommend wearing gloves, long sleeves, and appropriate PPE when handling, installing, or removing the blanket. Proper protective equipment ensures safe handling and prevents irritation.
Can I cut this blanket to a custom size myself?
While it can be cut, we do not recommend it because the woven fiberglass edges will fray and unravel quickly without a properly sewn hem. We offer 21 standard sizes, and if you need a specific dimension, DeBrovys provides custom fabrication services to ensure the edges are properly finished and grommeted.
What is the maximum continuous temperature rating?
The 24 oz. Insul-Shield has a continuous temperature rating of 1000°F (537°C) and an intermittent rating of 1500°F (815°C). These ratings ensure reliable performance in demanding thermal applications while maintaining structural integrity.
Are the grommets rust-resistant?
Yes, the grommets are made from heavy-duty brass, which is naturally rust-resistant and corrosion-resistant. This ensures the grommets will maintain their functionality and appearance even in harsh industrial environments or outdoor applications.
Can I use the Insul-Shield for outdoor applications?
Yes, the 24 oz. Insul-Shield can be used outdoors. The brass grommets are corrosion-resistant, and the heat-treated fiberglass is durable and weather-resistant. However, prolonged UV exposure may gradually affect the fiberglass, so we recommend covering the blanket when not in use for extended outdoor storage.
