Product Description
Beige Insul-Shield Heat Treated Fiberglass Fabric - 18 oz.
Lightweight lagging fabric developed for insulation pads, pipe lagging, safety barriers, safety curtains, garments and protective shields. Resists most acids, alkalies and solvents, with the exception of hydrofluoric acid and corrosive environments at elevated temperatures.
Specifications
| Fabric | Fiberglass |
| Weave | Plain Weave |
| Finish | Heat Treated |
| Construction | Warp 20 x Fill 14 |
| Thickness | 0.035 inches |
| Breaking Strength | Warp 200 lbs x Fill 100 lbs |
| Abrasion Resistance | 536 Cycles |
| Temperature Resistance | 1100°F / 593°C |
| K Factor | 0.3399 BTU/inch/hr/sq ft/°F |
| Color | Beige |
| Weight | 18 oz per sq. yd. |
Available Widths
- 40 inches
- 60 inches
- 72 inches
Applications
- Insulation pads
- Pipe lagging
- Safety barriers
- Safety curtains
- Garments
- Protective shields
Key Features
- 1100°F temperature resistance
- Heat treated finish for durability
- Available by the yard or by the roll (50 yards)
Made in USA | Flame Retardant Fabric
