ShurLink EZR Remote

ShurLink EZR Remote for Compatible Truck Tarp Systems

The ShurLink EZR Remote, part 1131576, is Shur-Co’s compact handheld controller for compatible ShurLink Wireless System applications. It is the straightforward, budget-focused ShurLink remote option for operators who want simple Open and Close control, replaceable AAA batteries, and the ability to manage up to five configured devices without the display, cradle, or two-way feedback features of the ShurLink PRO remote.

Use this remote only with a correctly installed and paired ShurLink receiver. Shur-Co identifies ShurLink as the platform that replaces SMART2 and SMART3 remote families; a legacy remote and an EZR remote are not automatically interchangeable. Confirm the installed receiver, application, required operating mode, and current remote family before ordering, pairing, or replacing a wireless controller.

Product Specifications

This product is the EZR remote only. Confirm the exact service need before ordering: a remote, receiver, conversion component, charging component, or another electrical-system part may be required depending on the equipment. The listed product price applies to the 1131576 ShurLink EZR remote configuration.

Who the EZR Remote Is Built For

The EZR is the practical choice when daily operation calls for a compact handheld controller and uncomplicated access to configured equipment. Shur-Co positions it as the budget-friendly ShurLink option with a compact design, simple two-button control, replaceable AAA batteries, and a protective lid. For an owner-operator, fleet driver, service department, or equipment manager, this can be a good fit when the desired workflow is clear command-and-control rather than screen-based status feedback.

It is not the same feature set as the ShurLink PRO Remote Kit with Cradle and Charging Cable. The PRO is the higher-feature option with a color display, rechargeable Li-Po battery, cradle charging, and two-way communication. The EZR intentionally omits the display and two-way communication, which makes correct component selection especially important when a buyer expects position feedback or a more information-rich remote experience.

ShurLink Wireless System Compatibility

ShurLink EZR, ShurLink PRO, the ShurLink app, and compatible receivers use the same ShurLink Wireless System. Shur-Co explains that the platform can be mixed and matched across compatible remotes, app functions, and receivers on a single trailer or train. The system uses advanced industrial Bluetooth technology, and the manufacturer lists wireless operation up to 150 feet; actual performance depends on installation, receiver placement, power, obstructions, and the operating environment.

Compatibility is not determined by remote appearance. The EZR remote will function only with ShurLink receivers; Shur-Co’s operating instructions state that the original SMARTransmitter, SMART1+, and SMART3 cannot be used with the EZR. If the equipment is older or has an uncertain service history, record the receiver identification, the equipment being controlled, the existing remote part number, and the requested operating functions before purchasing.

Five Channels for Equipment Organization

The EZR has five channels for controlling up to five different configured devices. Its Select control cycles through enabled channels, and unused channels can be disabled so operators do not need to step through unnecessary choices. That organization can be helpful for a truck or trailer with more than one compatible controlled function, provided each device has been installed, paired, and configured according to manufacturer instructions.

Receiver capacity is a separate concept. Shur-Co’s operating instructions state that a compatible receiver can accept signals from up to five paired remotes. Pairing is not completed at the factory: the operator or installer must pair each remote to the target receiver. During the manufacturer’s pairing procedure, the remote should be kept within 20 feet of the powered receiver. Do not attempt to use a remote that has not been properly paired to the receiver it is intended to control.

Open, Close, Momentary, and Express Operation

The EZR gives a channel either Momentary Mode or Express Mode when the compatible system has been configured for that behavior. In Momentary Mode, the Open or Close button must be held to operate the system. In Express Mode, an Open or Close command can continue operation until the equipment reaches its fully open or fully closed condition, subject to the application and its connected controls. Pressing a remote button or closing the lid can stop remote-commanded operation as described in the manufacturer instructions.

Express operation is not universal. Shur-Co specifies that encoder wires between the motor and control box must be connected for a channel to operate in Express Mode, and some products without encoder or other feedback operate only in Momentary Mode. The EZR ships with its first TARP channel configured for Express Mode and its other four channels configured for Manual Mode, but configuration should be reviewed for the actual application. Never select an operating mode based on assumption; follow the relevant system instructions and verify equipment movement in a clear, safe work area.

Battery Replacement and Power Management

The ShurLink EZR uses two AAA batteries. The manufacturer’s one-screw battery-access arrangement is designed to make replacement straightforward: unfasten the center screw, carefully open the battery cover, replace both batteries correctly, and close the remote. The instructions indicate that flashing lights at startup can warn of a low battery; at a lower battery level, the remote can turn off and the batteries must be replaced.

The protective lid serves an operating purpose as well as a protective one. Opening the lid powers the remote up; closing it powers the remote down. If left open after the last button press, the remote powers down after three minutes. Shur-Co also identifies the lid as a safeguard against accidental button operation. Close the lid after use, keep the remote protected, and replace both AAA batteries when the low-battery indication occurs rather than relying on a remote with uncertain power.

Pairing and Configuration Guidance

Pair the EZR only to the intended ShurLink receiver and follow the manufacturer’s procedure. The receiver must have 12-volt power, the appropriate remote channel must be selected, and both the receiver and remote are placed into Pair Mode. A successful pairing is confirmed through the receiver’s documented signal; an unsuccessful attempt times out and should be repeated only after the correct receiver, channel, power supply, and operating documentation have been confirmed.

Channel configuration lets an installer set each channel’s mode and enable or disable it. The remote will not activate a motor or lighting system while it is in Channel Configuration Mode. For fleet control, record the vehicle or trailer number, receiver, channel assignment, and equipment function in the maintenance record. Clear labeling and documented pairing reduce the risk that a replacement remote is paired to the wrong device or that a driver selects an unintended channel.

System Power and Safe Operation

Shur-Co’s EZR instructions include an important system-power notice: do not power the ShurLink EZR or any Shur-Co wireless system with a battery charger alone, because that can cause abnormalities or malfunction. Use the appropriate 12-volt truck or automobile battery power source for the trailer system as specified by the manufacturer. Inspect the entire control system—not only the handheld remote—when equipment does not respond as expected.

Before commanding a tarp, trap, gate, lighting function, or other controlled device, keep personnel clear of moving equipment and verify that the selected channel is correct. Stop operation if equipment binds, stalls, contacts an obstruction, or behaves unexpectedly. Remote controls do not replace trained operation, inspection, manufacturer instructions, or applicable lockout and work-area safety procedures.

EZR vs. ShurLink PRO: Choose the Feature Set You Need

Choose the EZR when simple channel-based control, replaceable AAA batteries, and its five-device capacity fit the application. Choose the PRO when the installed system and operating needs call for its display, two-way communication, position feedback, remote stop setup, more device capacity, or rechargeable-cradle workflow. Either remote must be matched to a compatible ShurLink system and correctly paired before use.

Truck Tarp System Parts and Resources

Browse Truck Tarp Systems to review compatible tarp-system parts and controls. For broader equipment planning, see the DeBrovys roll-off truck tarp systems guide and the DeBrovys blog. These resources can help identify the larger operating system before a remote or electrical component is selected.

If the service need involves a previous-generation remote, do not use the product title alone to decide what to order. The separately listed SMART2 Remote Cradle is a different legacy-family component and is not a substitute for an EZR remote. Provide the equipment model, receiver identification, old remote part number, and controlled application when requesting replacement guidance.

Minimum Order Fee Notice

Orders below $130.00 are subject to a $25.00 SHUR-CO minimum order fee. If your order total is $130 or below, you will be contacted with an additional invoice for the fee before your order ships. Consider grouping confirmed service parts into one order when appropriate for the maintenance plan.

Frequently Asked Questions

What is Shur-Co part 1131576?

Part 1131576 is the ShurLink EZR Remote, a compact handheld remote for compatible ShurLink Wireless System receivers. It is a different product from the ShurLink PRO remote kit and from legacy SMART-family components.

Will a ShurLink EZR Remote work with a SMART2 or SMART3 receiver?

Do not assume compatibility. Shur-Co’s EZR operating instructions state that EZR remotes function only with ShurLink receivers and that original SMARTransmitter, SMART1+, and SMART3 units cannot be used. Verify the installed receiver and manufacturer-approved conversion path before ordering.

How many devices can the EZR Remote control?

The EZR has five channels for controlling up to five configured devices. Enable only the channels used by the equipment so the operator can move through selections more clearly.

Does the ShurLink EZR have a rechargeable battery or charging cradle?

No. The EZR uses two replaceable AAA batteries and does not have a charging cradle. The ShurLink PRO is the separate remote option with a rechargeable Li-Po battery and USB type-C cradle charging.

Can the EZR run equipment in Express Mode?

It can use Express Mode only when the compatible equipment and connected encoder or feedback requirements support it. Systems without the required feedback operate in Momentary Mode. Confirm the system configuration and follow manufacturer instructions before relying on automatic operation.
